Chiller Lab Equipment 3850w 50L Coolant Circulation Pump

Minimum Order Quantity : 1 - 2 Units Price : $2,409.00
Packaging Details : Packing of Coolant Pump: carton or wooden case package, customized package is available. Supply Ability : 1000 Set/Sets per Month
Place of Origin: Henan, China Brand Name: Lanphan
Model Number: DLSB-50L

Detail Information

Pressure: High Pressure Structure: Multistage Pump
Lowest No-load Temperature: -30℃ Best Temperature Range: ≤25℃
Environmental Relative Humidity: ≤70% Temperature Display Mode: Liquid Crystal
Temperature Stability: ±2℃ Sensor Index: Pt100
Instrument Adjusting Range: ±150℃ Total Machine Power: 3850w
Safety Protection: Delay,leakage,over Current,overheat Refrigerant: R404A
Usage: Water Application: Cryogenic
Power: Electric Fuel: Electric
Port: Shanghai, Tianjin, Qingdao
High Light:

Refrigerant Coolant Circulation Pump

,

50L Coolant Circulation Pump

,

3850w Coolant Circulation Pump

Product Description

Chiller Lab Equipment 3850w 50L Coolant Circulation Pump

Product Description



The capacity of low temperature pump can be 5L-500L
Temperature ranges from room temperature to -120 degrees


Chiller Lab Equipment 3850w 50L Coolant Circulation Pump 0

The low temperature circulating pump is an essential equipment to make sure the normal working condition for the device adopting constant current and constant pressure to cool in the condition of water scarcity, poor quality of water and higher temperature. It can provide low temperature liquid for chemical reaction and medicine storage collocated with a rotary evaporator, a vacuum drying oven, a circulating water multiple pump, magnetic force stirrer. It is especially used for different kinds of chemical biology, physical lab which requires low temperature. It is the essential lab instrument for pharmacy, food industry, metallurgical industry and college scientific research.



The application of low temperature circulating pump: DLSB low temperature pump adopts mechanical refrigeration low temperature circulating equipment and provide constant current and constant voltage circulating liquid to meet the requirement of the decreasing instrument (electric microscope, electricity probe, x-ray machine, laser reactor and accelerator) so as to guarantee the required working temperature.




Chiller Lab Equipment 3850w 50L Coolant Circulation Pump 1

type DLSB 50L-30℃ DLSB 50L-30℃
Tank volume (L) 59.31 59.31
lowest no-load temperature(℃) -30
Using temperature range (℃) room temperature—-30
best temperature range(℃) ≤25
Environmental relative humidity (%) ≤70
Working power supply (V/HZ) single phase 220V 50HZ three phase 380/50
temperature display mode liquid crystal
temperature stability(℃) ±2
Sensor index Pt100
Instrument adjusting range (℃) ±150
set way Arbitrary adjustment of Settings in the range of use
safety protection delay,leakage,over current,over heat
  10℃ 4190 5475
Output refrigerating capacity(w) 0℃ 3354 4380
  -10℃ 2236 3285
  -20℃ 1397 1190
  -30℃ 559 1095
Total machine power (W) 2930 3850
Machine current (A) 13.8 5.4
refrigerant R404A R404A
  Power(W) 100 100
circulating pump Flow rate(L/min) 25 25
  lift(M) 7 7
Opening size(mm) 360×360 360×360
 tank shape
internal diameter and height of liquid storage tank(mm) 390×390×390 390×390×390
overall appearance size(mm) 760×615×1130 760×615×1130
machine weight(kg) 97 97



Chiller Lab Equipment 3850w 50L Coolant Circulation Pump 2Chiller Lab Equipment 3850w 50L Coolant Circulation Pump 3



Turn on and off:
The right turn to turn on the machine: Add the appropriate medium—connect the power with the special power supply—turn off the circulation switch—press the power button—open the circulation switch—open the switch—open the cooling equipment
The right turn to turn off the machine.Turn off the cooling equipment—turn off the switch—turn off the circulation switch(stirring switch)—turn off the outlet valve(or discharge the cooling medium)—turn off the power supply —disconnect circuit breaker—disconnect the power line from the power supply—clean the equipment.
Corollary Equipment

Chiller Lab Equipment 3850w 50L Coolant Circulation Pump 4

Related Products

Chiller Lab Equipment 3850w 50L Coolant Circulation Pump 5Chiller Lab Equipment 3850w 50L Coolant Circulation Pump 6

The capacity of our  pump can be 5L-500L
Temperature ranges  from room temperature to -120 degrees
