Chiller Lab Equipment Glycol Circulation Chiller machine 5L In Lab

Minimum Order Quantity : 1-2 Units Price : $2350
Packaging Details : Wooden Box or Customized Packing Delivery Time : 5-8 work days
Payment Terms : L/C, T/T, Western Union Supply Ability : 1000 Unit/Units per Month
Place of Origin: Henan, China Brand Name: Lanphan
Certification: CE, Model Number: DLSB 5L-80

Detail Information

Product Classification: Lab Chiller Unit Model: DLSB 5L-80
Temperature Fluctuation: ±2℃ Refrigerant: R404
Circulating Power: 280W Ambient Temperature: ≤ 25℃
Ambient Humidity: ≤ 70% Power Supply: 220V/60Hz
High Light:

20L Water Chiller Machine

,

Refrigeration Recirculate Water Chiller Machine

,

Lab 20L Water Chiller Machine

Product Description

Chiller Lab Equipment Glycol Circulation Chiller Machine 5L In Lab

Description of Chiller



DLSB-5L-10 chiller is also called low temperature cooling water circulating pump. This type of refrigeration pump has a water tank volume of 5L; adopts PT100 temperature sensor, which has a wide measurement range and good pressure resistance; uses difluoromethane (R22) as refrigerant, which has good cooling effect; uses compressor for mechanical refrigeration; The water circulation pump makes the cooled liquid circulate inside and outside through the pipeline, and can provide low temperature liquid and low temperature bath; it can be used with rotary evaporator, vacuum freeze drying oven, water circulation vacuum pump, magnetic stirrer and other equipment to carry out multi-functional chemical reaction.



Features of Chiller


Imported air-cooled hermetic compressor unit with advanced performance and reliable quality;

Special relays, protectors, capacitors, refrigeration components and imported high-quality components for refrigerant units;

Digital constant temperature display, microcomputer temperature control, simple and eye-catching operation;

Large cooling capacity and fast cooling speed, greatly improving work efficiency;

It can effectively protect all kinds of precision equipment and instruments to be used normally under water shortage conditions;

The circulation system is made of stainless steel, which has the functions of anti-corrosion, anti-rust and anti-cold liquid pollution;

The coolant can be delivered to the place of use at low temperature;

The original circulating pump of international famous factory is installed inside;

The microcomputer intelligently controls the refrigeration system to open automatically. The refrigeration system has multiple protection devices such as time delay, overheating, and overcurrent.



Application of Chiller



DLSB series chiller are suitable for chemical, biological and physical laboratories that need to maintain low temperature and normal temperature conditions. It is an essential equipment in the fields of medical and health, chemical industry, food, metallurgy, colleges and universities, scientific research, genetic engineering, polymer engineering and other fields. (The large-capacity low-temperature coolant circulation pump can be customized according to user needs.)



Technical Parameters of Chiller



Product Name Chiller
Model DLSB 5L-80℃
Minimum No-load Temperature -80℃
Temperature Fluctuation ±2℃
Coolant R404 R23
Refrigerating Capacity 168W-3308W
Total Machine Power 2490W
Cycle Power 100W
Circulating Pump Flow 23L
Head 11M
Ambient Temperature ≤25℃
Environment Humidity ≤70℃
Power Supply 110V60HZ
Working Current 28.5A

Chiller Lab Equipment Glycol Circulation Chiller machine 5L In Lab 0





Chiller Lab Equipment Glycol Circulation Chiller machine 5L In Lab 1

Chiller Lab Equipment Glycol Circulation Chiller machine 5L In Lab 2



Chiller Lab Equipment Glycol Circulation Chiller machine 5L In Lab 3

Chiller Lab Equipment Glycol Circulation Chiller machine 5L In Lab 4

 Chiller Lab Equipment Glycol Circulation Chiller machine 5L In Lab 5Chiller Lab Equipment Glycol Circulation Chiller machine 5L In Lab 6
