DLSB Chiller Lab Equipment Cryogenic Chiller Ethanol For Evaporator

Minimum Order Quantity : 1 - 2 Units Price : $567.00
Packaging Details : Packing : carton or wooden case package, customized package is available. Supply Ability : 1000 Set/Sets per Month
Place of Origin: Henan, China Brand Name: Lanphan
Certification: CE, ROHS

Detail Information

Applicable Industries: Manufacturing Plant, Food & Beverage Factory, Farms, Food Shop, Energy & Mining After Warranty Service: Video Technical Support, Online Support
Local Service Location: United States Showroom Location: United States
Video Outgoing-inspection: Provided Machinery Test Report: Provided
Marketing Type: Hot Product 2019 Warranty Of Core Components: 1 YEAR
Core Components: PLC, Engine, Gearbox, Motor Condition: NEW
Type: Water-Cooled Voltage: 110v/220v/380v
Dimension(L*W*H): 400*260*530 Mm Weight: 28KG
Warranty: 1 YEAR After-sales Service Provided: Video Technical Support, Online Support
Power(W): 420w Key Selling Points: High-accuracy
Tank Volume (L): 5 Lowest No-load Temperature(℃): -15
Using Temperature Range (℃): Room Temperature--15 Name: Industrial Mini Chiller
Environmental Relative Humidity (%): ≤70 Temperature Display Mode: Liquid Crystal
Sensor Index: Pt100 Instrument Adjusting Range (℃): ±150
Item: Portable Chiller Total Machine Power (W): 420W
Port: Shanghai, Tianjin, Qingdao
High Light:

28KG Portable Glycol Chiller

,

Water Cooled Portable Glycol Chiller

Product Description

DLSB Chiller Lab Equipment Cryogenic Chiller Ethanol For Evaporator

The capacity of our pump can be 5L-500L
Temperature ranges from room temperature to -120 degrees

Product Description



The DLSB-5 series low temperature coolant circulation pump can be used in laboratories, providing the cooling environment for small capacity of sample. It is especially suitable for chemical, biological and physical laboratories that need to maintain low temperature and normal temperature conditions. It is an essential equipment for medical and health, chemical industry, food industry, metallurgical industry, colleges and universities, scientific research, genetic engineering, polymer engineering and other fields. ( The large-capacity low-temperature coolant circulation pump can be customized according to user needs.)



DLSB Chiller Lab Equipment Cryogenic Chiller Ethanol For Evaporator 0

The DLSB-5 series low temperature coolant circulation pump ahopts the PT100 temperature sensor, with a wide measuring range and excellent pressure resistance. And the equipment uses difluoromethane(R22) as the refrigerant, having a better cooling effect. It is a low-temperature equipment that uses a compressor for mechanical refrigeration. The water circulating pump is added to enable the cooled liquid to pass through the pipeline for external and internal circulation, and can provide low temperature liquid and low temperature bath. It can also be combined with a rotary evaporator, a vacuum freeze drying oven, a water circulating vacuum pump, a magnetic stirrer and the like to perform multi-functional chemical reaction operations and drug storage at a low temperature.

DLSB Chiller Lab Equipment Cryogenic Chiller Ethanol For Evaporator 1

Model name DLSB 5L-10°C
Tank volume (L) 5
lowest no-load temperature(°C) -15
Using temperature range (°C) room temperature—-15
best temperature range(°C) 5~25
Environmental relative humidity (%) ≤70
Working power supply (V/HZ) single phase220-50
temperature display mode liquid crystal
temperature stability(°C) ±2
Sensor index Pt100

Instrument adjusting range (°C) ±150
set way Arbitrary adjustment of Settings in the range of use
safety protection delay,leakage,over current,overheat
output refrigerating capacity (W) 10°C 620
0°C 460
-10°C 280
-20°C -
Total machine power (W) 420
Machine current (A) 2.1
refrigerant 134A
Circulating pump Power(w) 100
Flow rate(L/min) 20
Lift(M) 4~6
external loop interface Threaded joint 12 inches
opening size(mm) 160×160
tank shape square
Internal diameter and height of liquid storage tank (mm) 170×170×170
Overall appearance size (mm) 400×260×530
Machine weight (kg) 28
fuse 5A
matching parts one set

DLSB Chiller Lab Equipment Cryogenic Chiller Ethanol For Evaporator 2DLSB Chiller Lab Equipment Cryogenic Chiller Ethanol For Evaporator 3



Turn on and off:
The right turn to turn on the machine: Add the appropriate medium—connect the power with the special power supply—turn off the circulation switch—press the power button—open the circulation switch—open the switch—open the cooling equipment
The right turn to turn off the machine.Turn off the cooling equipment—turn off the switch—turn off the circulation switch(stirring switch)—turn off the outlet valve(or discharge the cooling medium)—turn off the power supply —disconnect circuit breaker—disconnect the power line from the power supply—clean the equipment.
Corollary Equipment

DLSB Chiller Lab Equipment Cryogenic Chiller Ethanol For Evaporator 4

Related Products

DLSB Chiller Lab Equipment Cryogenic Chiller Ethanol For Evaporator 5DLSB Chiller Lab Equipment Cryogenic Chiller Ethanol For Evaporator 6

The capacity of our pump can be 5L-500L
Temperature ranges  from room temperature to -120 degrees

Glycol Portable Chiller Industrial Mini Chiller
