220v Circulating Pump 20L Laboratory Water Chiller

Minimum Order Quantity : 1 - 2 Units Price : $1,870.00
Packaging Details : Packing of temperatur chiller: carton or wooden case package, customized package is available. Supply Ability : 1000 Set/Sets per Month
Place of Origin: Henan, China Brand Name: Lanphan
Certification: CE, ROHS

Detail Information

Applicable Industries: Manufacturing Plant, Food & Beverage Factory, Energy & Mining, Food & Beverage Shops After Warranty Service: Video Technical Support, Online Support
Local Service Location: United States Showroom Location: United States
Condition: New Type: Water-Cooled
Voltage: 220v Dimension(L*W*H): 660*515*990 Mm
Weight: 60KG Warranty: 1 YEAR
After-sales Service Provided: Video Technical Support, Online Support Power(W): 1350
Working Temperature Range: > -30℃ Key Selling Points: High-accuracy
Lowest No-load Temperature: -30℃ Best Temperature Range: ≤25℃
Environmental Relative Humidity: ≤70% Temperature Display Mode: Liquid Crystal
Temperature Stability: ±2℃ Sensor Index: Pt100
Instrument Adjusting Range: ±150℃ Total Machine Power: 1350
Name: Temperatur Chiller Refrigerant: R404A
Port: Shanghai, Tianjin, Qingdao
High Light:

20L Laboratory Water Chiller


Circulating Pump Laboratory Water Chiller


220v Circulating Pump 220v Circulating Pump 20L Laboratory Water Chiller

Product Description

20L Laboratory Circulating Pump Temperatur Chiller

The capacity of our pump can be 5L-500L
Temperature ranges from room temperature to -120 degrees

Product Description

220v Circulating Pump 20L Laboratory Water Chiller 0


It is an essential equipment for medical and health, chemical industry, food industry, metallurgical industry, colleges and universities, scientific research, genetic engineering, polymer engineering and other fields. ( The large-capacity low-temperature coolant circulation pump can be customized according to user needs.) It can maintain constant current and pressure. The circulating fluid can provide cooling water to meet the requirements of temperature and water purity, for large equipment such as high purity metal, rare substance purification, environmental experiment and magnetron sputtering, vacuum coating, etc. The low temperature coolant circulation pump can also meet the cooling needs of electronic instruments, electronic probes, ultra-high vacuum sputtering instruments, X-ray machines, lasers, accelerating leveling lamp and other valuable equipment.




220v Circulating Pump 20L Laboratory Water Chiller 1

Type DLSB 20L-30°C
Tank volume (L) 24.38
lowest no-load temperature(°C) -30
Using temperature range (°C) room temperature—-30
best temperature range(°C) ≤25
Environmental relative humidity (%) ≤70
Working power supply (V/HZ) single phase220/50
temperature display mode liquid crystal
temperature stability(°C) ±2
Sensor index Pt100
Instrument adjusting range (°C) ±150
set way Arbitrary adjustment of Settings in the range of use
safety protection delay,leakage,over current,over heat
  10°C 1845
  0°C 1476
Output refrigerating capacity(w) -10°C 984
  -20°C 615
  -30°C 246
Total machine power (W) 1350
Machine current (A) 7.2
refrigerant R404A
circulating pump power(w) 100
flow rate(L/min) 20
lift(m) 6
external loop interface(mm) 14
opening size(mm) 260L×260
tank shape square
internal diameter and height of liquid storage tank(mm) 290×290×290
overall appearance size(mm) 565×460×845
machine weight(kg) 60
fuse 15A



220v Circulating Pump 20L Laboratory Water Chiller 2220v Circulating Pump 20L Laboratory Water Chiller 3


Turn on and off:
The right turn to turn on the machine: Add the appropriate medium—connect the power with the special power supply—turn off the circulation switch—press the power button—open the circulation switch—open the switch—open the cooling equipment
The right turn to turn off the machine.Turn off the cooling equipment—turn off the switch—turn off the circulation switch(stirring switch)—turn off the outlet valve(or discharge the cooling medium)—turn off the power supply —disconnect circuit breaker—disconnect the power line from the power supply—clean the equipment.
Corollary Equipment

220v Circulating Pump 20L Laboratory Water Chiller 4

Related Products

220v Circulating Pump 20L Laboratory Water Chiller 5220v Circulating Pump 20L Laboratory Water Chiller 6

The capacity of our refrigeration pump can be 5L-500L
Temperature ranges  from room temperature to -120 degrees
