Automatic Stainless Steel Rotary Tablet Press 11e 17e 80kn Cartoon Candy Cake Decoration

Minimum Order Quantity : 1 Unit Price : $8666/pc
Packaging Details : Carton, wooden cases or customizable package Delivery Time : 5-8 work days
Payment Terms : T/T, L/C, Western Union Supply Ability : 800 Units per Month
Place of Origin: China Brand Name: Lanphan
Certification: CE Model Number: 11E/17E

Detail Information

Product Name: Automatic Tablet Press Voltage: 380V
Dimension: 880*750*1600 Warranty: 1 Year
Weight: 580kg Material: Stainless Steel
Structure: Fully Enclosed Housing Model: 11E, 17E
Turret Speed: 0-25r/min Max Pressure: 80kn
High Light:

17e Automatic Rotary Tablet Press

,

Automatic Stainless Steel Rotary Tablet Press

,

25r/min Automatic Tablet Press

Product Description

Rotary Tablet Press ZP11E Cartoon Candy Tablet Press Cake Decoration Candy Tablet Press

The tablet machine high degree of automation, the provincial workers, save time, may be a multi-purpose machines, one for multi-machine control.

Main Technical Specifications

Model ZP226-11E ZP226-17E
No.of Stations 11 17
Max Production Capacity(pcs/h) 16500 25500
Turret Speed(r/min) 0-25
Max Pressure(kn) 80
Max Filling Depth(mm) 20
Max Tablet Thickness(mm) 1-8
Max Tablet Diameter(mm) Ф40
Motor Power(kw) 3KW/380V,50Hz,Three phase five wire system
Overall Size(mm) 880*750*1600
Machine Weight(kg) 580



Automatic Stainless Steel Rotary Tablet Press 11e 17e 80kn Cartoon Candy Cake Decoration 0

Applications:

Automatic Stainless Steel Rotary Tablet Press 11e 17e 80kn Cartoon Candy Cake Decoration 1

This machine is suitable for pressing various kinds of granular materials into round tablet or different geometrical shape tablets.The machine is an automatically continuous rotary tablet press that are widely used in pharmaceutical, chemical, ceramics, foodstuff , electronics, plastics and powder metallurgy industries , etc.

- Pharmaceutical: Chinese tablets, Western medicine, plain films, chewable tablet, calcium tablet, buccal tablet, propolis tablet (bee propolis tablet), spiraling tablet, effervescent tablet-pioneer, camphor ball etc.
- Foodstuff: candy pieces, flake coffee, chicken essence chunk, seasoning chunk, glucose tablet, milk powder candy etc.
- Agriculture: wafer feed, fertilizer chunk, animal food etc.
- Chemical: bleaching powder, ceramic powder, powder metallurgy, magnetic materials, antiseptic, powdered carbon-molecular sieve etc.
- Electronic: carbon brush, button cell, electronic component etc.

Product show

Automatic Stainless Steel Rotary Tablet Press 11e 17e 80kn Cartoon Candy Cake Decoration 2

Descriptions: This machine is used to press the granular raw material into the round tablets or various geometric shaped tablets, it is especially caters for small scale production. When pressing the tablets, the rotary disc speed and filling depth of material can be adjustable.
In addition, it is equipped with the force-feeder and overload protection devices. So This machine is also suitable for viscous materials.

Product Advantage

Automatic Stainless Steel Rotary Tablet Press 11e 17e 80kn Cartoon Candy Cake Decoration 3

Product Details

- The material of the cover and internal table are made of stainless steel.The housing is fully closed. The surface of turntable is specially disposed to keep the surface luster and prevent it from being polluted.This series conform to GMP standard governing the medicine production and quality control. The tablet-paint.
- Equipped a force-feeder on this machine.
- The lay-out of all the controllers and the operate parts is reasonable.
- All the drive devices are located inside the machine so keep the machine clean.
- Overload protection unit is included in the system to avid the damage of the punches and apparatus, When overload occurs, the machine will stop working automatically.
- This machine also has electromagnetic brake motor and other safety protection device which can be adjusted and operated when running.

Automatic Stainless Steel Rotary Tablet Press 11e 17e 80kn Cartoon Candy Cake Decoration 4

Packing & Shipping

Automatic Stainless Steel Rotary Tablet Press 11e 17e 80kn Cartoon Candy Cake Decoration 5
