Vertical Autoclave Sterilizer 35L 50L 75L 100L Electric 0.22Mpa

Minimum Order Quantity : 1 set Price : $699-1450
Packaging Details : Wooden Box or Customized Packing Delivery Time : 10-15 days
Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram Supply Ability : 100 Sets per Month
Place of Origin: Henan, China Brand Name: Lanphan
Certification: CE ISO Model Number: LPLS-HD

Detail Information

Product Name: LPLS-HD Autoclave Volume: 35L 50L 70L 10L
Working Pressure: 0.22Mpa Working Temperature: 134℃
Max Working Pressure: 0.23MPa Heat Average: ≤1℃
Timer: 0-99min
High Light:

Electric Vertical Autoclave Sterilizer

,

35L Vertical Autoclave Sterilizer

,

0.22Mpa Vertical Autoclave Sterilizer

Product Description

Product Parameter

Model technical data LS-35HD(automatic) LS-50HDI(automatic) LS-75HD(automatic) LS-100HD(automatic)
Chamber volume 35L(φ318×450)mm 50L(φ340×550) mm 75L(φ400×600) mm 100L(φ440×650) mm
working pressure 0.22MPa
Working temperature 134℃
Max working pressure 0.23 Mpa
Heat average ≤1℃
Timer 0~99min or 0~99hour59min
Adjustment of temperature 105~134℃
Power 2.5Kw/AC220V.50Hz 3Kw/AC220V.50Hz 4.5Kw/AC220V.50Hz
Overall dimension 470×450×1020(mm) 520×500×1150(mm) 550×530×1180 (mm) 580×560×1290 (mm)
Transport dimension 540×540×1140(mm) 580×580×1250(mm) 610×610×1280(mm) 640×640×1360(mm)
G.W/N.W 81Kg/63Kg 94Kg/ 74Kg 113Kg/ 93Kg 125Kg/ 105Kg

Autoclave Description



Vertical pressure steam sterilizer (LPLS-35HD, LPLS-50HD, LPLS-75HD, LPLS-100HD, referred to as sterilizer) is a device that uses saturated steam to sterilize items. The sterilization chamber structure of this type of sterilizer is a single-layer structure, the steam supply is heated by an intrusive electric heating tube, the gas replacement method is a lower exhaust type, the sealing structure type is a beam structure, and the control method is microcomputer control.



Vertical Autoclave Sterilizer 35L 50L 75L 100L Electric 0.22Mpa 0

Vertical Autoclave Sterilizer 35L 50L 75L 100L Electric 0.22Mpa 1



Vertical Autoclave Sterilizer 35L 50L 75L 100L Electric 0.22Mpa 2Vertical Autoclave Sterilizer 35L 50L 75L 100L Electric 0.22Mpa 3
