Closed Loop Extraction Machine Mirror Polish Vacuum 45g Mini

Minimum Order Quantity : 1 set Price : $529
Packaging Details : Wooden Box or Customized Packing Delivery Time : 7-12 days
Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram Supply Ability : 100 Sets per Month
Place of Origin: Henan, China Brand Name: Lanphan
Certification: CE ISO Model Number: MCLE-0.1

Detail Information

Product Name: Closed Loop Extractor Polish: Mirror Polish
Volume: 45g Material: SS304
Rated Pressure: 150psi Temperature Range: -42℃~72℃
Dimension: 310mm*310mm*155mm Weight: 7.5kg
High Light:

BHO Closed Loop Extraction Machine

,

1L Closed Loop Extraction Machine

,

Closed Loop Extraction Machine 150psi

Product Description

Closed Loop Extraction Machine Mirror Polish Vacuum 45g Mini



Product Description



The closed loop extractor, known as well-received cannabis extraction equipment, widely used in chemical, metallurgical, food and other industries. A closed-loop extractor kit mainly consists of three parts: a solvent tank, a material column and a receiving foundation. Some upgraded versions add a dewaxing column as the fourth part, or equip the material column with a dewaxing structure directly.



Working Process



The working process of a closed loop extractor can be described as follows. The materials are put into the material column to get soaked by ethanol or other solvents. In this process, substances get extracted. Then the mixture will be transferred into next column and get separated. The solvents will be transferred into next column and the extract will be saved in the bottom container for users to get. In a closed loop extractor, the solvents can be recycled and used for several times, which is very economical for users and very environmentally friendly for people.

Product Types

There are several types of closed loop extractors.

In terms of ways of solvent injection, closed loop extractors can be classified into the top filled closed loop extractors and the bi-directional closed loop extractors.

In terms of ways of solvent movement, closed loop extractors can be classified into the passive closed loop extractors and the active closed loop extractors.



Function and Purpose



The function of closed loop extractor is mostly to extract solvents from solid substance. And it is widely and mainly used in industry, for example, the extraction of cannabis, which is extracting cannabis from cannabis leaves by ethanol’s washing.



With the rapid development of industry, the extraction of cannabis by ethanol’s washing becomes more and more popular around the world. Now let us introduce the use of closed loop extractor on extraction of cannabis by ethanol’s washing for you .



The extraction of cannabis by ethanol’s washing is to extract cannabinoid from cannabis leaves through closed loop extractor by ethanol’s washing. In the process, cannabis leaves will be put into solvent and fully washed by ethanol. During the washing process, the cannabinoid which is soluble will be removed out and then collected in the collection tank. The production of cannabinoid has two using ways, the one is used as medicine and the other one is used as entertainment supplies.



Product Parameter



Product Name Closed Loop Extractor
Product Model MCLE-0.1
Volume 45g(0.1LB)
Material Stainless steel 304
Surface Mirror polishing
Standard 3A Health standard
Gasket type Fluorine rubber
Rated pressure 150psi
Operating temperature range ‘-42℃-72℃
System limit vacuum 10 μmHg
Dimension 310*310*155,7.5kg



Closed Loop Extraction Machine Mirror Polish Vacuum 45g Mini 0

Closed Loop Extraction Machine Mirror Polish Vacuum 45g Mini 1Closed Loop Extraction Machine Mirror Polish Vacuum 45g Mini 2

Closed Loop Extraction Machine Mirror Polish Vacuum 45g Mini 3
