5lb Closed Loop Extraction Machine

Minimum Order Quantity : 1 - 2 Sets Price : $3,000.00
Packaging Details : Packing: carton or wooden case package, customized package is available. Supply Ability : 600 Unit/Units per Month
Place of Origin: Henan, China Brand Name: Lanphan
Model Number: L-5LB

Detail Information

Technics: Forged Connection: Flange
Shape: Reducing Head Code: Square
Name: 5lb Closed Loop Extractor Polish: Mirror Polish
Seal: Flange,mesh Gasket Capacity: 1LB
Stainless Construction: SS304 Port: Shanghai, Tianjin, Qingdao
High Light:

5lb Closed Loop Extraction Machine

,

stainless steel Closed Loop Extraction Machine

Product Description



stainless steel 1lb bho 5lb closed loop extractor



Product Description



The closed loop extractor is a device used to extract solvents from solid substance. It is widely used in cannabis concentrates in industry. In the whole process, there are several parts serving the extraction of solvents. Solvents can be used and recycled in the closed loop extractor, which is very economical for users and very environmental friendly for people. The equipment primarily consists of three parts: a solvent tank, a material column and a receiving foundation. Some upgraded versions add a dewaxing column as the fourth part, or equip the material column with a dewaxing structure directly.



Product Advantages

  • High production.
  • More than 99% of the solvent can be recovered.
  • Independent port for vacuum, injection and recovery.
  • Remove the pollution in the solvent and oil.
  • No gas exposed to air.
  • Environmental protection.
  • Modular design for easy upgrade.

5lb Closed Loop Extraction Machine 0

5lb Closed Loop Extraction Machine 1



The equipment primarily consists of three parts: a solvent tank, a material column and a receiving foundation. Some upgraded versions add a dewaxing column as the fourth part, or equip the material column with a dewaxing structure directly. The closed loop hydrocarbon extraction system is used to conduct a plant extraction in a sealed vacuum system. The closed-loop system can be kept during the plant extraction without exposing any solvent to the air. The butane, propane or the combination of them are generally used as the solvent.



There are several types of closed loop extractors. In terms of ways of solvent injection, closed loop extractors can be classified into the top filled closed loop extractors and the bi-directional closed loop extractors. In terms of ways of solvent movement, closed loop extractors can be classified into the passive closed loop extractors and the active closed loop extractors.


The accessories of closed loop extractor
01. High pressure food grade hoses: the tube used to transfer liquid phase butane
02. Solvent tank: the container used to contain solvents
03. Product tubes: the tube used to transfer production
04. Collection chamber: the container used to collect oil
05. Recovery pump:used to provide pressure to recover the solvents
06. Material column: the reactor that cannabis gets extracted



polish mirror polish
seal Flange,mesh gasket
Capacity 1LB
Stainless construction SS304
