Home Freeze Dryer Sublimation Dehydrator Meat

Minimum Order Quantity : 1 set Price : $ 1599-3599
Packaging Details : Wooden Box or Customized Packing Delivery Time : 5-8 work days
Payment Terms : L/C, D/A, D/P, T/T, Western Union Supply Ability : 100 Sets per Month
Place of Origin: Henan Brand Name: Lanphan
Certification: CE ISO Model Number: HFD-1

Detail Information

Product Name: Home Freeze Dryer Freeze-dried Area: 0.1㎡
Cold Trap Coil Temperature: <-40℃ (no-load) Ultimate Vacuum: 15pa (no-load)
Power Supply: 220V 50HZ Power: 750W
Handling Capacity: 1-2KG / Batch Layer Spacing: 45mm
Weight: 50KG Dimension: 400mm X 550mm X700mm
High Light:

Setup Meat Home Freeze Dryer

,

12LBS/Batch Home Freeze Dryer

,

Sublimation Home Freeze Dryer

Product Description

Home Freeze Dryer Sublimation Dehydrator Meat



Home Freeze Dryer Parameter


Product Model KWD-HFD-1
Freeze-dried Area 0.1㎡
Cold Trap Coil Temperature <-40℃ (no-load)
Ultimate Vacuum 15pa (no-load)
Power Supply 220V 50HZ
Power 750W
Handling Capacity 1-2KG / batch
Layer Spacing 45mm
Weight 50KG
Material Tray Size 140mm x 278mm three layers
Dimension 400mm x 550mm x700mm





Freeze Drying Technology

Vacuum freeze drying technology, also known as sublimation drying, is a method to pre-freeze water-containing material and sublimate its moisture under vacuum. The original biological and chemical properties of freeze-dried items are basically unchanged, which is easy to keep for a long time. After adding water, they can be restored to the state before freeze-drying and maintain their original biochemical properties. Therefore, vacuum freeze drying technology is widely used in pharmaceutical, food, chemical, biological products and other fields.

Home Freeze Dryer Features

Integrated structure, small size, easy to use, no leakage
Materials in contact with the product meet food grade requirements
The cold trap is made of stainless steel, which is anti-corrosion and easy to clean
With sample pre-freezing function
The cold trap captures ice evenly; strong ice capture ability
International famous brand compressor, which are high efficiency, energy saving, long service life, low noise.
Well-known brand vacuum pump, which are high pumping speed and higher ultimate vacuum.
Intelligently record and export data

Freeze Drying is used for


The vacuum freeze dryer is suitable for the drying of materials, such as high-end raw materials, Chinese herbal medicine, biological, wild vegetables, dehydrated vegetables, food, fruits, chemicals, pharmaceutical intermediates, etc.

Freeze Drying and Drying

Drying is one of the methods to keep the substance undamaged. There are many drying methods, such as sun-drying, boil-drying, drying and so on. But these methods are all carried out at a temperature above 0°C. The product obtained by drying will shrink in volume and harden in texture. Most of the volatile components will be lost, and some heat-sensitive substances such as protein and vitamins will be denatured. Therefore, the properties of the dried product are quite different from those before drying.
Different from the above drying methods, freeze-drying technology is the best way to dry materials. The drying of the product is basically carried out at a temperature below 0°C. Freeze-drying technology is particularly suitable for many heat-sensitive substances. For example, proteins and microorganisms will not be denatured or lose their biological vitality. Therefore, it is widely used in medicine.

Home Freeze Dryer Sublimation Dehydrator Meat 0Home Freeze Dryer Sublimation Dehydrator Meat 1Home Freeze Dryer Sublimation Dehydrator Meat 2Home Freeze Dryer Sublimation Dehydrator Meat 3

Home Freeze Dryer Sublimation Dehydrator Meat 4Home Freeze Dryer Sublimation Dehydrator Meat 5Home Freeze Dryer Sublimation Dehydrator Meat 6
