High Efficiency 3.5 M2 Stainless Steel 14 Trays HFD-35 Food Freeze Dryer

High Efficiency 3.5 M2 Stainless Steel 14 Trays HFD-35 Food Freeze Dryer

3.5 M2 stainless steel freeze dryer

14 trays food freeze dryer

HFD-35 high efficiency freeze dryer

Place of Origin:

Henan, China

Brand Name:

Lanphan

Certification:

contact us

Model Number:

HFD-35

Contact Us
Request A Quote
High Efficiency 3.5 M2 Stainless Steel 14 Trays HFD-35 Food Freeze Dryer
High Efficiency 3.5 M2 Stainless Steel 14 Trays HFD-35 Food Freeze Dryer High Efficiency 3.5 M2 Stainless Steel 14 Trays HFD-35 Food Freeze Dryer High Efficiency 3.5 M2 Stainless Steel 14 Trays HFD-35 Food Freeze Dryer High Efficiency 3.5 M2 Stainless Steel 14 Trays HFD-35 Food Freeze Dryer
Product Details
Type:
Food Freeze Dryer
Total Power:
5.5KW
Voltage:
220v/50Hz(110V/380V)
Cold Trap Temperature:
-70℃
Capacity:
50-55kg/batch
Material Tray Size:
400*600*30mm(14 Trays)
Warranty:
12 Months
After-sales Service Provided:
Online Service
Weight:
322KG
Application:
Fruit, Vegetable,liquid...
Highlight:

3.5 M2 stainless steel freeze dryer

,

14 trays food freeze dryer

,

HFD-35 high efficiency freeze dryer

Payment & Shipping Terms
Minimum Order Quantity
1 unit
Price
$8999/unit
Packaging Details
wooden box packing
Delivery Time
10-30 working days
Payment Terms
L/C, T/T, Paypal, Alipay...
Supply Ability
50 units per month
RELATED PRODUCTS
Good price High Efficiency 3.5 M2 Stainless Steel 14 Trays HFD-35 Food Freeze Dryer online Video

High Efficiency 3.5 M2 Stainless Steel 14 Trays HFD-35 Food Freeze Dryer

Get Best Price
Good price High Vacuum Performance 50-55 KG Capacity HFD-35 Vacuum Drying Equipment online Video

High Vacuum Performance 50-55 KG Capacity HFD-35 Vacuum Drying Equipment

Get Best Price
Good price HFD-35 -70℃ Ultra Low Temperature 5500w Industrial Freeze Drying Machine For Food Fruit Vegetable online Video

HFD-35 -70℃ Ultra Low Temperature 5500w Industrial Freeze Drying Machine For Food Fruit Vegetable

Get Best Price
Good price HFD-35 Commercial Freeze Dryer 3.5sqm 35-40 KG/Batch14 Trays Large Scale Lyophilizer online Video

HFD-35 Commercial Freeze Dryer 3.5sqm 35-40 KG/Batch14 Trays Large Scale Lyophilizer

Get Best Price
Contact Us
+8613783661974
yang@lanphan.com
Contact Now
Product Description

High Efficiency 3.5 M2 Stainless Steel 14 Trays HFD-35 Food Freeze Dryer​

Food Freeze Dryer Parameter

High Efficiency 3.5 M2 Stainless Steel 14 Trays HFD-35 Food Freeze Dryer 0

Model HFD-35
Tray space 3.5m2
Cold trap temperature -70ºC
Number of trays 14pcs
Processing capacity 50-55 kg/batch
Material tray size 400*600*30mm
Power supply 220V/50HZ can be customized 110V or 380V
Layer Spacing 45mm
Overall power 5500W


Food Freeze Dryer Application

High Efficiency 3.5 M2 Stainless Steel 14 Trays HFD-35 Food Freeze Dryer 1

Food Freeze Dryer Advantages

The 7-layer freeze dryer machine with 14 trays provides sufficient freeze-drying space.
Each layer has a temperature probe to ensure that each layer and each tray can be in a precise temperature environment
Dual compressors

  • Ultra-Low Condensing Temperatures: Our advanced refrigeration technology achieves a deep-freeze condensing temperature as low as -70℃, ensuring efficient vapor capture and superior sublimation for sensitive materials.

  • Massive Refrigeration Capacity: By leveraging twin-compressor synergy, the system generates significantly more cooling power, enabling rapid pull-down speeds and shorter overall processing times.

  • Enhanced System Redundancy & Stability: Each unit operates with an independent control circuit and dedicated protection devices. This dual-system design ensures maximum operational uptime and prevents batch loss during critical drying stages.

  • Superior Thermal Precision: The dual-stage cooling allows for finer temperature modulation, providing the consistent, stable environment necessary for preserving the bioactivity and structural integrity of your products.

High Efficiency 3.5 M2 Stainless Steel 14 Trays HFD-35 Food Freeze Dryer 2High Efficiency 3.5 M2 Stainless Steel 14 Trays HFD-35 Food Freeze Dryer 3



The water trap chamber and the drying chamber are separate.
1. Avoid cross contamination: Avoid the moisture or impurities in the water trap chamber to reverse pollute the materials in the drying chamber, so as to ensure the purity and quality of the product.
2.Improve drying efficiency: the drying chamber and the water capture chamber have independent temperature control systems and vacuum systems respectively, which canbe precisely regulated according to their respective needs.

Food Freeze Dryer Details

High Efficiency 3.5 M2 Stainless Steel 14 Trays HFD-35 Food Freeze Dryer 4

Food Freeze Dryer Factory Attend Exhibitions

High Efficiency 3.5 M2 Stainless Steel 14 Trays HFD-35 Food Freeze Dryer 5
