Name: -75°C Precision Pilot Lyophilizer Vacuum Freeze Dryer with Automatic Stoppering System
Brand: Henan Lanphan Industry Co.,Ltd
SKU: LGJ-100
Price: 21300 USD
Availability: InStock

Home > Products > Vacuum Freeze Dryer >

-75°C Precision Pilot Lyophilizer Vacuum Freeze Dryer with Automatic Stoppering System

-75°C precision vacuum freeze dryer

automatic stoppering freeze dryer

pilot lyophilizer with stoppering system

Place of Origin:

Henan, China

Brand Name:

Lanphan

Certification:

Model Number:

LGJ-100

Request A Quote

-75°C Precision Pilot Lyophilizer Vacuum Freeze Dryer with Automatic Stoppering System

Product Details

Type:

Pilot Freeze Dryer

Condition:

New

Capacity:

15kg/batch

Power(w):

7500W

Cold Trap Temperature:

-75℃

Vacuum Degree:

<10 Pa

Main Material:

SS304

After-sales Service Provided:

Online Support

Warranty:

One Year

Dimension(l*w*h):

1140x1720x1910mm

Weight:

742Kg

Highlight:

-75°C precision vacuum freeze dryer

automatic stoppering freeze dryer

pilot lyophilizer with stoppering system

Payment & Shipping Terms

Minimum Order Quantity

1 unit

Price

$21300/unit

Packaging Details

wooden box package

Delivery Time

15 working days

Payment Terms

T/T

Supply Ability

5 units per month

Automatic Stoppering Freeze Dryer Pilot Lyophilizer with Precision Temperature Control

Get Best Price

-75℃ 15 kg/batch Pilot Freeze Dryer Automatic Hydraulic In-Situ Stoppering Lyophilizer

Get Best Price

1.1M2 Automatic Hydraulic Stoppering Vacuum Freeze Dryer with Oil Heating for Vials

Get Best Price

Video

Large Stainless Steel Food Freeze Dryer Fruit Flower Industrial Freeze Drying Machine

Get Best Price

+8613783661974

yang@lanphan.com

Contact Now

Product Description

-75°C Precision Pilot Lyophilizer Vacuum Freeze Dryer with Automatic Stoppering System

TECHNICAL SPECIFICATIONS

Freeze-Drying Area	1.1 m2
Condenser Temperature(No-load)	≤-75℃
Batch Capacity	15 kg/batch
Ultimate Vacuum (No-load)	< 10 Pa
Tray Size	470*600 mm
Number of Trays	4 trays
Tray Spacing	80 mm
Pumping Speed	15 L/s
Ice Capture Capacity	> 15 kg
Noise Level	<80 dB
Power	7500 W
Main Material	304 Stainless Steel
Power Supply	3-phase 5-wire 380V, optional 220V
Overall Dimensions	114017201910 mm
Net Weight	742 kg

-75°C Precision Pilot Lyophilizer Vacuum Freeze Dryer with Automatic Stoppering System

Wide Applications
Biopharmaceuticals and Pilot-Scale Upscaling: Vaccines, antibodies, diagnostic kits, and process optimization for converting liquid-filled vials to lyophilized powder.
High-Value Food and Health Supplements: Ginseng, Cordyceps, active probiotic freeze-dried powder, bird's nest, and specialty protein powders.
Fine Chemicals and Advanced Materials: Graphene, aerogels, nanocatalysts, and specialty ceramic powders.

-75°C Precision Pilot Lyophilizer Vacuum Freeze Dryer with Automatic Stoppering System
