Professional HFD-35 Freeze Dryer Ultimate Vacuum < 2Pa with 8L/S Pumping Rate

Professional HFD-35 Freeze Dryer Ultimate Vacuum < 2Pa with 8L/S Pumping Rate

Professional freeze dryer with vacuum pump

8L/S pumping rate freeze dryer

Ultimate vacuum freeze dryer under 2Pa

Place of Origin:

Henan, China

Brand Name:

Lanphan

Certification:

contact us

Model Number:

HFD-35

Contact Us
Request A Quote
Professional HFD-35 Freeze Dryer Ultimate Vacuum < 2Pa with 8L/S Pumping Rate
Professional HFD-35 Freeze Dryer Ultimate Vacuum < 2Pa with 8L/S Pumping Rate Professional HFD-35 Freeze Dryer Ultimate Vacuum < 2Pa with 8L/S Pumping Rate Professional HFD-35 Freeze Dryer Ultimate Vacuum < 2Pa with 8L/S Pumping Rate Professional HFD-35 Freeze Dryer Ultimate Vacuum < 2Pa with 8L/S Pumping Rate
Product Details
Type:
Freeze Dryer
Total Power:
5.5KW
Voltage:
220v/50Hz(110V/380V)
Cold Trap Temperature:
-70℃
Capacity:
50-55kg/batch
Material Tray Size:
400*600*30mm(14 Trays)
Warranty:
12 Months
After-sales Service Provided:
Online Service
Weight:
322KG
Application:
Fruit, Vegetable,liquid...
Highlight:

Professional freeze dryer with vacuum pump

,

8L/S pumping rate freeze dryer

,

Ultimate vacuum freeze dryer under 2Pa

Payment & Shipping Terms
Minimum Order Quantity
1 unit
Price
$8999/unit
Packaging Details
wooden box packing
Delivery Time
10-30 working days
Payment Terms
L/C, T/T, Paypal, Alipay...
Supply Ability
50 units per month
RELATED PRODUCTS
Good price 5500W Power Vacuum Lyophilizer 3.5M2 Drying Area for Commercial Use online Video

5500W Power Vacuum Lyophilizer 3.5M2 Drying Area for Commercial Use

Get Best Price
Good price High-Efficiency 14 Trays & 50-55 KG/24H Ice Capacity HFD-35 Freeze Drying Machine online Video

High-Efficiency 14 Trays & 50-55 KG/24H Ice Capacity HFD-35 Freeze Drying Machine

Get Best Price
Good price 3.5 M2 Shelf Area & 35-40 KG Large Batch Capacity HFD-35 Vacuum Freeze Dryer online Video

3.5 M2 Shelf Area & 35-40 KG Large Batch Capacity HFD-35 Vacuum Freeze Dryer

Get Best Price
Good price Industrial Freeze Dryer with Embraco Compressor &-55°C Cold Trap Temperature online Video

Industrial Freeze Dryer with Embraco Compressor &-55°C Cold Trap Temperature

Get Best Price
Contact Us
+8613783661974
yang@lanphan.com
Contact Now
Product Description

3.5 M2 Shelf Area & 35-40 KG Large Batch Capacity HFD-35 Vacuum Freeze Dryer

Freeze Dryer Parameter

Professional HFD-35 Freeze Dryer Ultimate Vacuum < 2Pa with 8L/S Pumping Rate 0

Model HFD-35
Tray space 3.5m2
Cold trap temperature -70ºC
Number of trays 14pcs
Processing capacity 50-55 kg/batch
Material tray size 400*600*30mm
Power supply 220V/50HZ can be customized 110V or 380V
Layer Spacing 45mm
Overall power 5500W


Freeze Dryer Application

Professional HFD-35 Freeze Dryer Ultimate Vacuum < 2Pa with 8L/S Pumping Rate 1

Freeze Dryer Advantages

The 7-layer freeze dryer machine with 14 trays provides sufficient freeze-drying space.
Each layer has a temperature probe to ensure that each layer and each tray can be in a precise temperature environment
Dual compressors
1. Lower condensing temperature: Lower condensing temperature can be achieved, which can be as low as-70 ℃.
2. Stronger refrigeration capacity: two compressors work together, more refrigeration power, faster refrigeration.
3. Higher system stability: Each compressor in the dual compressor system has an independent control system and protection device.
4. More accurate temperature control.

Professional HFD-35 Freeze Dryer Ultimate Vacuum < 2Pa with 8L/S Pumping Rate 2Professional HFD-35 Freeze Dryer Ultimate Vacuum < 2Pa with 8L/S Pumping Rate 3



The water trap chamber and the drying chamber are separate.
1. Avoid cross contamination: Avoid the moisture or impurities in the water trap chamber to reverse pollute the materials in the drying chamber, so as to ensure the purity and quality of the product.
2.Improve drying efficiency: the drying chamber and the water capture chamber have independent temperature control systems and vacuum systems respectively, which canbe precisely regulated according to their respective needs.

Freeze Dryer Details

Professional HFD-35 Freeze Dryer Ultimate Vacuum < 2Pa with 8L/S Pumping Rate 4

Freeze Dryer Factory Attend Exhibitions

Professional HFD-35 Freeze Dryer Ultimate Vacuum < 2Pa with 8L/S Pumping Rate 5
