Name: 5L Spray Dryer Machine Stainless Steel Spray Drying System Spray Drying Machine For Milk
Brand: Henan Lanphan Industry Co.,Ltd
SKU: LPSD-5
Price: 6500 USD
Availability: InStock

Home > Products > Spray Dryer Machine >

5L Spray Dryer Machine Stainless Steel Spray Drying System Spray Drying Machine For Milk

Milk Spray Dryer Machine

Stainless Steel Spray Dryer Machine

5L Spray Dryer Machine

Place of Origin:

China

Brand Name:

Lanphan

Certification:

CE ISO

Model Number:

LPSD-5

Request A Quote

Product Details

Product Name:

Spray Dryer Machine

Minimum Feed Volume:

Total Power:

11KW /380V

Air Volume:

≤250(m³/h)

Nozzle Diameter:

1.00mm (Optional)

Nozzle Speed:

36000r/min(adjustable)

Feeding Way:

Peristaltic Pump Adjustment

After Warranty Service:

Online Support

Highlight:

Milk Spray Dryer Machine

Stainless Steel Spray Dryer Machine

5L Spray Dryer Machine

Payment & Shipping Terms

Minimum Order Quantity

1 Unit

Price

$6500/Unit

Packaging Details

Custom wooden case packing

Delivery Time

7-15 days

Payment Terms

L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability

500 Sets per Month

Mini Lab 2l Glass Spray Dryer For Make Milk Flavor Powder Fruit Juice Powder

Get Best Price

Video

Mini 2000ml Glass Coffee Egg Powder Spray Dryer Machine for Sugar Syrup Detergent

Get Best Price

Video

1500ml/H ~2000ml/H Glass Laboratory Spray Dryer for Tomato Milk Coffee Egg Powder Whey

Get Best Price

Video

2L/H Atomizer Spray Dryer Spray Drying System Spray Drying Machine for Milk

Get Best Price

+8613783661974

yang@lanphan.com

Contact Now

Product Description

5L Spray Dryer Machine Stainless Steel Spray Drying System Spray Drying Machine For Milk

Spray Dryer Machine Advantages

Fast drying speed: Spray dryers can quickly atomize liquid into tiny droplets and evaporate quickly in the hot air flow, so the drying speed is fast, which is very important for industrial production processes that require fast drying.

Controllable particle size: By adjusting the operating parameters such as the nozzle, the size of the solid particles formed can be relatively accurately controlled, which is very important for applications with special requirements for particle size, such as food, chemical and other industries.

Controllable humidity: By adjusting the operating parameters, the humidity of the resulting solid particles can also be controlled, which is very useful for some products with high or low humidity requirements, such as milk powder, etc.

Suitable for heat-sensitive materials: Spray dryers are usually suitable for heat-sensitive materials due to their short drying time. Through appropriate operating parameters, the exposure time of heat-sensitive materials can be minimized to maintain product quality.

Continuous production can be achieved: Spray dryers can usually be designed with continuous production capacity, which improves production efficiency and is suitable for large-scale industrial production.

Suitable for a variety of materials: Spray dryers are suitable for processing a variety of materials, including liquids, suspensions, slurries, etc., and are widely used in various industries.

Easy operation and high degree of automation: The spray dryer is relatively simple to operate and can be easily integrated with the automation system to improve production efficiency.

Spray Dryer Machine Parameter

5L Spray Dryer Machine Stainless Steel Spray Drying System Spray Drying Machine For Milk 0

Product name	5L centrifugal spray dryer
Air inlet temperature control	RT~300ºC
The largest feed rate	5000mL/H(adjustable)
Feeding way	Peristaltic pump adjustment
Nozzle speed	36000r/min(adjustable)
Nozzle diameter	1.00mm
Dryer time	2.0 ~ 3.0S
Air volume	≤250(m³/h)
Total power	11KW /380V

Spray Dryer Machine Description

5L Spray Dryer Machine Stainless Steel Spray Drying System Spray Drying Machine For Milk 2
