Higher Efficiency Centrifugal Spray Dryer Milk Powder Stainless Steel 28kw

Minimum Order Quantity : 1 set Price : $11299
Packaging Details : Wooden Box or Customized Packing Delivery Time : 10-12 days
Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram Supply Ability : 100 Sets per Month
Place of Origin: China Brand Name: Lanphan
Certification: CE ISO Model Number: HF-10

Detail Information

Name: Large Spray Dryer Total Power: 28kw/380v
Mean Drying Time (s): 1-1.5 Temperature Control Accuracy (℃): ±1
Minimum Feeding Amount (ml/h): 200 Maximum Feeding Capacity (ml/h): 10000
High Light:

Higher Efficiency Centrifugal Spray Dryer

,

Milk Powder Centrifugal Spray Dryer

,

28kw Centrifugal Spray Dryer

Product Description



Higher Efficiency Milk Powder Making Stainless Steel Milk Spray Drying Machine



Product Parameter



Product Name Large Spray Dryer
Inlet air temperature control (℃) 180~250
Air outlet temperature control (℃) 80~90
Centrifugal nozzle speed 22000rpm
Water evaporation (ml/h) 10kg/H
Maximum feeding capacity (ml/h) 10000
Minimum feeding amount (ml/h) 200
Mode of feed Peristaltic pump regulation
Temperature control accuracy (℃) ±1
Mean drying time (s) 1~1.5
Total Power 28kw/380v
Stainless steel drying tower size (mm) Diameter1400 height 2700
Product Dimension(mm) 2500x1500x2600
Package Dimension(mm) 2600x1600x2800



Product Application


Various fields where the production of a free powder sample is required.
LPG-10L has successfully processed samples in the following areas: Beverage, Flavours and colourings, Milk and egg products, Plant and vegetable extracts, Pharmaceuticals, Synthetics Heat sensitive materials, Plastics polymers and resins, Perfumes, Blood, Ceramics and superconductors Biochemicals, Dyestuffs, Soaps and detergents, Foodstuffs, Adehesives, Oxides, Textiles, Bones, Teeth and tooth amalgam and many others.



Spray drying machine operating step:

  • Start red total power supply.
  • LCD screen: Chinese and English.
  • Start fan.
  • Start heating set 150-220 (general common temperature).
  • Outlet temperature reach over 80 degree.
  • Start atomizer.
  • Outlet temperature between 85-100.
  • Start peristaltic pump feeding material, peristaltic pump set 20. (please note: before start peristaltic pump, please ensure drying tower and collection flask is dryer, without water or liquid ).
  • Outlet temperature reach over 100 degrees, peristaltic pump speed set 30.40.50.60.70.80.90.100.
  • Outlet temperature is controlled by the set air inlet temperature and peristaltic pump material feeding quantity.
