Customized Sublimation Dryer 8 Trays Stainless Steel

Customized Sublimation Dryer 8 Trays Stainless Steel

customized stainless steel vacuum freeze dryer

8 trays sublimation dryer

corrosion proof sublimation dryer

Place of Origin:

China,Henan

Brand Name:

Lanphan

Certification:

CE

Model Number:

HFD-8

Contact Us
Request A Quote
Product Details
Name:
Freeze Drying Equipment
Voltage:
110V/220V
Condition:
New
Power(w):
2500W
Dimension(l*w*h):
875mmx825mmx1540mm
Application:
Food Processing
Warranty:
ONE YEAR
Weight(kg):
212
Material:
Stainless Steel
Highlight:

customized stainless steel vacuum freeze dryer

,

8 trays sublimation dryer

,

corrosion proof sublimation dryer

Payment & Shipping Terms
Minimum Order Quantity
1 unit
Price
$4500/unit
Packaging Details
wooden carton package
Delivery Time
3-8 days
Payment Terms
T/T, Western Union...
Supply Ability
1000 pcs per month
Product Description

Customized Sublimation Dryer 8 Trays Stainless Steel 0

Main features

  • The machine adopts Danfoss compressor, rapid cooling
  • LCD screen control, easy to operation, and powerful function
  • The door of the drying chamber is made of colorless and transparent organic glass, allowing the entire freeze-drying process to be observed.
  • The vacuum pump adopts international standard KF quick connector connection.
  • Stable performance, easy operation and low noise.



Product application

Customized Sublimation Dryer 8 Trays Stainless Steel 1

Vacuum freeze drying technology, also known as sublimation drying, is a method of pre-freezing water-containing substances and sublimating the water under vacuum. The original biological and chemical properties of freeze-dried products remain basically unchanged and are easy to store for a long time. After adding water, it can be restored to the state before freeze-drying and maintain its original biochemical characteristics. Therefore, vacuum freeze-drying technology is widely used in medicine, food, chemical industry, biological products and other fields.Freeze-dried food can be stored for up to 25 years. Freeze-dried food is ideal for home storage.

The samples with high acid or solvent content can not be dried in the absence of special protection (if necessary, please contact the service department), otherwise the freeze dryer may be corroded. When drying containing azide should pay more attention to it, because with copper or other non ferrous metal reaction will explode.

Product parameter

Customized Sublimation Dryer 8 Trays Stainless Steel 2



Product Model HFD-8
Freeze-dried area 1 M2
Processing capacity 10-12 kg/batch
Tray quantity 8pcs
Tray size(mm) 265*435*25
Spacing between partitions 40mm
Power(W) 2500
Ultimate vacuum 15Pa
Cold trap temperature ≤-40ºC
Temperature probe independent probe
Compressor French Danfoss brand
Frame Iron frame + Plastic spraying


Attentions

  1. Must use a grounded power outlet.
  2. Working environment temperature≤32℃, the humidity≤80%.
  3. After drying finished, open the vent valve to inflate air at first, then close the vacuum pump to prevent sample contaminated by the pump oil. If a sudden power outage, open the vent valve immediately, and take out the samples as soon as possible, properly stored.
  4. Keep the seal ring clean, and cannot Scrub with organic solvents.
  5. Replace the vacuum pump’s oil after working 100 hours, check and maintenance the pump regularly.
  6. Do not frequently switch power supply and refrigerator, If the refrigerator is shut down caused by operation, at least three minutes to wait, and then restart the refrigerator

Product details

Customized Sublimation Dryer 8 Trays Stainless Steel 3

Our Factory

Customized Sublimation Dryer 8 Trays Stainless Steel 4

Related product

Customized Sublimation Dryer 8 Trays Stainless Steel 5

Packing & Shipping

Customized Sublimation Dryer 8 Trays Stainless Steel 6

After-Sale Service

During installation and adjustment period, our after-sale service staff will communicate with customers frequently to know product's running state in time. Assist customers to install and adjust products until customers are satisfied;
If product has malfunction during operation period, we'll offer you satisfied answer in time. We'll reply you within 1 hour and provide solution or send staff to spot within 24 hours after receiving maintenance notification;
Lifelong free technical support. Conduct satisfaction survey and inquiry equipment running condition to clients by telephone or e-mail semiannually from the first day of equipment running, put on records of acquired information;
Provide assistance in solving problems such as equipment damage in the transport.
