Oils Cbd Short Path Distillation System for Lab

Oils Cbd Short Path Distillation System for Lab

Oils Cbd Short Path Distillation System

Lab Short Path Distillation System

ODM Short Path Distillation System

Place of Origin:

Henan, China

Brand Name:

Lanphan

Certification:

CE

Contact Us
Request A Quote
Product Details
Applicable Industries:
Lab
After Warranty Service:
Video Technical Support, Online Support
Local Service Location:
United States
Showroom Location:
United States
Video Outgoing-inspection:
Provided
Machinery Test Report:
Provided
Marketing Type:
Hot Product 2019
Warranty Of Core Components:
1 YEAR
Core Components:
Gearbox, Pressure Vessel, Gear
Condition:
New
Power Source:
Electric
Process:
Vacuum Distillation
Voltage:
220V/110V
Dimension(L*W*H):
580*580*735 Mm
Weight:
24kg
Warranty:
1 YEAR
After-sales Service Provided:
Online Support
Key Selling Points:
Easy To Operate
Working Temperature:
5-40
Vaccuum Degree:
0.098 Mpa
Remarks:
Cbd Short Path Distillation
Constant Pressure Funnel Volume:
1 L
Port:
Shanghai, Tianjin, Qingdao
Highlight:

Oils Cbd Short Path Distillation System

,

Lab Short Path Distillation System

,

ODM Short Path Distillation System

Payment & Shipping Terms
Minimum Order Quantity
1 - 2 Units
Price
$886.00
Packaging Details
Packaging: carton or wooden case package, customized package is available
Supply Ability
40000 Unit/Units per Month
Product Description

Short Path Kit Quick Delivery Equipment Oils Cbd Distillation



Working principles of centrifuge extractor

Lanphan PP centrifuge is to use centrifugal force to accelerate the liquid phase in the solid-liquid mixed
liquid out of the rotating drum, and leave the solid phase in the rotating drum, so that the different materials that need to be separated can be accelerated to separate the machine.The operator should fill the filter bag with crushed plant material and places it in the machine. Then, add alcohol until the plant material is submerged. After soaking at low temperature and setting a program to rotate at a low speed in both directions,the active ingredients in the plant are fully extracted. Rotate at high speed and open the bottom discharge valve to discharge the extract.

Products Description
Oils Cbd Short Path Distillation System for Lab 0
Oils Cbd Short Path Distillation System for Lab 1
Oils Cbd Short Path Distillation System for Lab 2
Oils Cbd Short Path Distillation System for Lab 3
Oils Cbd Short Path Distillation System for Lab 4



Oils Cbd Short Path Distillation System for Lab 5
Model

SPD-2L
SPD-5L
SPD-10L
SPD-20L
Material

Borosilicate Glass 3.3



Heating Temperature

Ambient to 300℃



Working Pressure

Around 5 Pa



Distillation Vessel
Volume(L)
2
5
10
20

Size
2×24/40 joint
34/45 joint
24/40 joint
24/40 joint
2×34/45 joint
45/50 joint
2×29/42 joint
Receiving Vessel
Volume(ML)
2×500 ml
1×500ml
1×1000ml
2×1000ml
2×2000ml
2×2000ml
2×5000ml

Size
24/40 joint
24/40 joint
24/40 joint
29/42 joint
Cold Trap
Dry Ice Volume(L)
1 L

2 PCS×1L

Heating Mantle
Heating Power (w)
650
1100
2100
3000

Heating Power (w)
50-1800




Motor Power (w)
40



Vacuum pump
Pumping Rate(L/S)
2
4
4
6
Cooling Circulator
Cooling Temperature
-10℃~85℃



General
Voltage
110V 60HZ or 220V 50/60HZ,1 Phase



Corollary Equipment
Oils Cbd Short Path Distillation System for Lab 6
Oils Cbd Short Path Distillation System for Lab 7
Turnkey project
Oils Cbd Short Path Distillation System for Lab 8
