Lab Rotary Evaporator Ethanol Vacuum Condenser Thermal Evaporation Equipment

Minimum Order Quantity : 1 Price : $850
Packaging Details : Carton, wooden cases or customizable package Delivery Time : 5-8 work days
Payment Terms : L/C, T/T, Western Union Supply Ability : 1000 Unit/Units per Month
Place of Origin: Henan Brand Name: Lanphan
Certification: CE Model Number: RE-501

Detail Information

Name: RE-501 Rotary Evaporator Product Classification: Lab Rotary Evaporator
Glass Material: GG-17 Bracket Material: Stainless Steel
Rotating Bottle Volume: 5L Collection Bottle Volume: 3L
Vacuum Degree: 0.098Mpa Packaging Weight: 38KG
High Light:

5L Lab Rotary Evaporator

,

40W Vacuum Thermal Evaporation Equipment

,

120rpm Vacuum Lab Rotary Evaporator

Product Description

Lab Rotary Evaporator Ethanol Vacuum Condenser Thermal Evaporation Equipment



Rotary Evaporator Description



RE-501 rotary evaporator is a common lab instrument used in chemical laboratory. It’s mainly adopted to distill a large amount of volatile solvents continuously under the negative pressure. It is capable of separating and purifying reaction products especially for the concentration of liquid extract and distillation of receiving fluid during the chromatographic separation. As the evaporator is vacuumized, the boiling point of the solvent to be distilled decreases. In general, the component distilled from the sample is the target component in the chemical research, such as extracting some natural component from organic synthesis sample. Generally, the rotary evaporator is used to separate components with low boiling points, such as ethane and ehtyl acetate, which are liquids at room temperature and normal pressure. Furthermore, some component in the sample can be removed through standard operation.



Circulating Vacuum Pump


Rotary evaporator matching use with circulating water vacuum pump to offer a vacuum environment for reduced pressure distillation, they are widely used for vacuum filtration, vacuum evaporation, vacuum degassing, etc



Low Temperature Coolant Circulation Pump


Rotary evaporator matching use with DLSB series low temperature cooling liquid circulating pump to conduct chemical reaction and medicine storage which requires low temperature.





Lab Rotary Evaporator Ethanol Vacuum Condenser Thermal Evaporation Equipment 0



Rotary Evaporator Parameters



Basic Parameter Type RE-501
Glass Material GG-17
Support Material stainless steel
Shell Material Antisepsis Plastic Spraying 310*320*240mm
Inner Container Material stainless steel 280*170mm
Baseboard Size 350*330mm
Volume of Rotary Bottle 5L ¢50 flange aperture
Volume of Recycling Bottle 3L 35# ground aperture
Vacuum Degree 0.098Mpa
Rotating Power 40W
Rotating Speed 0-120rpm
Heating Power 2KW
Temperature Control Range of Bath Kettle 400°C
Temperature Accuracy ±1°C
Voltage/Frequency (V/Hz) 220V/50Hz
Up and Down Distance 120mm
Shape Size(mm*mm*mm) 700*335*1009mm
Package Size(mm*mm*mm) 1040*620*410 0.26 m³
Package Weight (KG) 38
Function Allocation Speed Adjustment Mode Electrodeless Speed Regulation
Rotate Speed Display Mode Digital Display
Temperature Display Mode Digital Display K Type Sensor
Temperature Control Mode Smart Temperature Control
Sealing Mode PTFE Sealing
Condenser Vertical Condenser 100*510mm 29#Standard Aperture
Up and Down Mode Manual Up and Down of Bath Kettle
Continuous Charging Standard Aperture Feeding Valve
Vacuum Display Mode Vacuum Meter
Optional Equipping Anti-splash Device Equipping Transparent Cover of Bath Kettle
Anti-explosion Anti-explosion Frequency Changer, Anti-explosion Dynamo EX40We
Frame Part Plastic Spraying or PTFE Spraying



Corollary Equipment



Lab Rotary Evaporator Ethanol Vacuum Condenser Thermal Evaporation Equipment 1







Certiefications



Lab Rotary Evaporator Ethanol Vacuum Condenser Thermal Evaporation Equipment 2
