lanphan Vacuum Distillation Lab Rotary Evaporator

lanphan Vacuum Distillation Lab Rotary Evaporator

lanphan Lab Rotary Evaporator

Vacuum Distillation Lab Rotary Evaporator

Place of Origin:

Henan, China

Brand Name:

Lanphan

Certification:

CE

Contact Us
Request A Quote
Product Details
Applicable Industries:
Manufacturing Plant, Machinery Repair Shops, Energy & Mining
After Warranty Service:
Video Technical Support, Online Support
Local Service Location:
United States
Showroom Location:
United States
Video Outgoing-inspection:
Provided
Machinery Test Report:
Provided
Marketing Type:
Ordinary Product
Warranty Of Core Components:
1 YEAR
Core Components:
Bearing, Gearbox, Motor, Gear
Condition:
New
Power Source:
Electric
Process:
Vacuum Distillation
Voltage:
220V/110V
Power(W):
40W
Dimension(L*W*H):
630*560*540mm
Weight:
26kg
Warranty:
1 YEAR
After-sales Service Provided:
Online Support
Key Selling Points:
High Productivity
Name:
Rotating Evaporator
Rotating Speed:
0-120rpm
Rotating Speed Display:
LCD
Volume Of Recycling Bottle:
1L
Vacuum Degree:
0.098Mpa
Selling Units:
Single Item
Single Package Size :
63X63X49 Cm
Single Gross Weight:
25.000 Kg
Package Type:
Rotating Evaporator: Carton Or Wooden Case Package, Customized Package Is Available.
Highlight:

lanphan Lab Rotary Evaporator

,

Vacuum Distillation Lab Rotary Evaporator

Payment & Shipping Terms
Minimum Order Quantity
1-2 Units
Price
$905.00
Product Description



lanphan reliable manufacturer glass rotating evaporator



Product Description

RE-2000E rotary evaporator is a newly designed new generation smart rotary evaporator, it adopts double row high-capacity blue backlight LCD as the human-computer interface, control part use high-performance single chip as main control chip, adopt special control program according to controlled member, beauty in appearance and stable in property. Besides, it has reserved updating connector, which can update software to meet client requirements.


RE-2000E rotary evaporator has following features:
1. Use PTFE water bath kettle, which is heat preservation, energy-saving, anti-explosion, splash-proof, rust protection and anti-pollution;
2. Primary member use rust protected aluminum alloy and special engineering plastic, that is durable in use and beauty in appearance;
3. Has the function of temperature and rotating speed, double display of temperature and rotating speed;
4. Components use new-type interface design, easy to assemble;
5. Double sealed by PTFE and fluorine rubber sealing ring to keep high vacuum degree;
6. Use advanced PID temperature control to control temperature accurately;
7. Whole body adopts building block design, that is strong in expand ability;
8. It can smoothly up and down, easy to handle and latch position;
9. Equipped with efficient vertical condensate glass component, condensation area can reach up to 1500cm², fast condensation speed, recovery rate almost 100%;
10. Has the function of dry burning resistant protection and safe temperature loop;
11. Has a wide speed regulation range, can set temperature freely within 0-180rpm;
12. Durable design, can choose plate bursting disk glass component as needed.





Parameter Type RE-2000E
Glass Material GG-17
Support Material Aluminum alloy
Shell Material PTFE recombination, full-closed heating
Volume of Rotary Bottle 1L 24# Standard Aperture
Volume of Recycling Bottle 1L 35# Standard Aperture
Vacuum Degree 0.098Mpa
Rotating Power 40W Brushless Electric Machine
Rotating Speed 0-180rpm
Heating Power 1.5KW
Temperature Control Range of Bath Kettle 0-99℃
Temperature Accuracy ±1℃
Voltage/Frequency (V/Hz) 220V/50Hz
Up and Down Distance 120mm
Shape Size(mm*mm*mm) 660*420*830
Package Size(mm*mm*mm) 630*560*540 0.19m³
Package Weight (KG) 26
Function Allocation Speed Adjustment Mode Electrodeless Speed Regulation
Rotating Speed Display Mode LCD
Temperature Display Mode PT100 Sensor digital display
Temperature Control Mode Smart Temperature Control
Sealing Mode Telfon Sealing
Condenser Vertical Condenser 85*430mm
Up and Down Mode Automatic Up and Down of Main Engine
Continuous Charging 19# Standard Aperture Feeding Valve
Optional Equipping Anti-splash Device Equipping Transparent Cover of Bath Kettle
Heating Method oil bath 0-400℃
Material of Bath Kettle whole 304 stainless steel
Our company's laboratory glass and laboratory instruments are independent research and development, available for custom-made according to client requirements.



lanphan Vacuum Distillation Lab Rotary Evaporator 0

lanphan Vacuum Distillation Lab Rotary Evaporator 1lanphan Vacuum Distillation Lab Rotary Evaporator 2

Basic
Rotary evaporator, also called rotavap or rotovap, is a commonly used lab instrument in chemistry laboratory, mainly used in continuous distillation of a large amount of volatile solvent under negative pressure. Especially for the concentration of extract liquor and distillation of receive liquid when chromatograph. Because evaporator is vacuumized, to be distilled solvent’s boiling point depressed. In general, ingredient which is distilled form sample is the target ingredient in chemical research, such as extracting some natural ingredient from organic synthesis sample. Rotary evaporator mostly is used for isolating low-boiling ingredient, such as hexane, ethyl acetate, that presenting liquid state under indoor temperature and normal pressure. Besides, it can dislodge some ingredient in sample by standard operation.
Related Products

lanphan Vacuum Distillation Lab Rotary Evaporator 3lanphan Vacuum Distillation Lab Rotary Evaporator 4



Corollary Equipment

lanphan Vacuum Distillation Lab Rotary Evaporator 5

1.Rotary evaporator matching use with circulating water vacuum pump to offer a vacuum environment for reduced pressure distillation, they are widely used for vacuum filtration, vacuum evaporation, vacuum degassing, etc.
2.Rotary evaporator matching use with GDSZ series high and low temperature circulating pump to quickly cooling or warming, the circulating pump is an efficient equipment for quick temperature adjustment.
3.Rotary evaporator matching use with DLSB series low temperature cooling liquid circulating pump to conduct chemical reaction and medicine storage which requires low temperature environment.
